Insulrock Panel
These fire rated panels are made with a non-combustible mineral wool core. They are strong and stiff panels that can withstand a great deal of weight and force. The low thermal conductivity that acts as an insulator, helps keep buildings cool in the summer and warm in the winter. These panels are moisture/ impact resistant and very easy to install. Available in a variety of thicknesses and sizes. Contact us to get a quote. Uses: Fire Rated Exterior Wall, Partition Wall, Liner Wall, Ceiling
- Resists high temperatures, does not burn or release gases in a fire.
- One-step installation that can easily be disassembled and reinstalled.
- Will not expand as it is dimensionally stable and water repellent.
- Sound reduction acoustical properties due to mineral wool.
Thermal Safe
Coverage Width: 42″
Interior & Exterior Gauge: 24GA, 26 GA
Interior & Exterior Face: G-90 galvanized or AZ-50 aluminum-zinc coated steel.
Length: 8′-0″ to 40′-0″, variable by thickness.
Thickness: 3″, 4″, 5″, 6″, 7″, 8″
or
Insulrock
Coverage Width: 47.375”
Gauge: Interior- 26GA; Exterior – 26GA, 24GA
Length: 8’ to maximum 30’.
Thickness: 4”, 5”, 6”, 8”, 10”, 12”
Joint: Double tongue-and-groove with spline
